Art.-Nr. G 35-10GV

wire mesh tray

Mesh cable tray, U-shaped, height = 38 mm

The U-shaped G 35 mesh cable tray has a side height of 38 mm and is available in tray widths from 116 to 618 mm. The standard length is 3004 mm. For the routing of light cables and conduits, especially for direct and raised floor installation and intermediate floors. A variety of materials and finishes are available to meet the corrosion requirements of a wide range of applications.
The GVE mesh cable tray connector must be used for the G 35 mesh cable tray.

Art.-Nr.
G 35-10GV
height
38 mm
width
116 mm
length
3004 mm
Material strength profile
4.00 mm
distributed load control cable
0.04 kN/m
cross section area
29 cm2
Weight per storage unit
1.690 kg
No stepping
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

L

length

t

Material strength profile

QSK

distributed load control cable

A

cross section area

G

Weight per storage unit

  • G 35-10S
    wire
    height
    38 mm
    width
    116 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.04 kN/m
    cross section area
    29 cm2
    Weight per storage unit
    1.690 kg
    More information
  • G 35-15S
    wire
    height
    38 mm
    width
    166 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.07 kN/m
    cross section area
    43 cm2
    Weight per storage unit
    1.850 kg
    More information
  • G 35-20S
    wire
    height
    38 mm
    width
    216 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.09 kN/m
    cross section area
    58 cm2
    Weight per storage unit
    2.590 kg
    More information
  • G 35-30S
    wire
    height
    38 mm
    width
    316 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.13 kN/m
    cross section area
    87 cm2
    Weight per storage unit
    3.500 kg
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

L

length

t

Material strength profile

QSK

distributed load control cable

A

cross section area

G

Weight per storage unit

  • G 35-10F
    wire mesh tray
    height
    38 mm
    width
    116 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.04 kN/m
    cross section area
    29 cm2
    Weight per storage unit
    1.810 kg
    More information
  • G 35-15F
    wire mesh tray
    height
    38 mm
    width
    166 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.07 kN/m
    cross section area
    43 cm2
    Weight per storage unit
    1.980 kg
    More information
  • G 35-20F
    wire mesh tray
    height
    38 mm
    width
    216 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.09 kN/m
    cross section area
    58 cm2
    Weight per storage unit
    2.780 kg
    More information
  • G 35-30F
    wire mesh tray
    height
    38 mm
    width
    316 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.13 kN/m
    cross section area
    87 cm2
    Weight per storage unit
    3.740 kg
    More information

steel, galvanic zinc plated

Article

H

height

B

width

L

length

t

Material strength profile

QSK

distributed load control cable

A

cross section area

G

Weight per storage unit

  • G 35-10GV
    wire mesh tray
    height
    38 mm
    width
    116 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.04 kN/m
    cross section area
    29 cm2
    Weight per storage unit
    1.690 kg
    More information
  • G 35-15GV
    wire mesh tray
    height
    38 mm
    width
    166 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.07 kN/m
    cross section area
    43 cm2
    Weight per storage unit
    1.850 kg
    More information
  • G 35-20GV
    wire mesh tray
    height
    38 mm
    width
    216 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.09 kN/m
    cross section area
    58 cm2
    Weight per storage unit
    2.590 kg
    More information
  • G 35-30GV
    wire mesh tray
    height
    38 mm
    width
    316 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.13 kN/m
    cross section area
    87 cm2
    Weight per storage unit
    3.500 kg
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

B

width

L

length

t

Material strength profile

QSK

distributed load control cable

A

cross section area

G

Weight per storage unit

  • G 35-10E
    wire mesh tray
    height
    38 mm
    width
    116 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.04 kN/m
    cross section area
    29 cm2
    Weight per storage unit
    1.690 kg
    More information
  • G 35-15E
    wire mesh tray
    height
    38 mm
    width
    166 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.07 kN/m
    cross section area
    43 cm2
    Weight per storage unit
    1.850 kg
    More information
  • G 35-20E
    wire mesh tray
    height
    38 mm
    width
    216 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.09 kN/m
    cross section area
    58 cm2
    Weight per storage unit
    2.590 kg
    More information
  • G 35-30E
    wire mesh tray
    height
    38 mm
    width
    316 mm
    length
    3004 mm
    Material strength profile
    4.00 mm
    distributed load control cable
    0.13 kN/m
    cross section area
    87 cm2
    Weight per storage unit
    3.500 kg
    More information

Details

  • No stepping

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Downloads

    • de

    • en

    Cable trays - Assembly instructions

    Assembly instructions for G 50, G 100, GI, GTD 30, GTDW, GVR, GV 30, GVD 30, GVU, GVK, GV-L, GBH, GBHK, GTR, GK-A, GD, GDR, GD-SW,

    PDF

    Choose languageChoose language

    Cable trays - Assembly instructions

    Choose language to download

    • de

    • en

    Mesh cable trays - Technical information

    Technical Information

    PDF

    Choose languageChoose language

    Mesh cable trays - Technical information

    Choose language to download

    • de

    Mesh cable trays G - Compact overview

    Compact overview of mesh cable trays and accessories: G 50, G 100, GDR, GD, GKAB, DB, DKSL, KDU, KDAG, KHUSS, GBAG, HB, KWF, KHA, KW, KA, connectors, dividers, spacer brackets

    PDF (532.66 KB)

    DownloadDownload

    • de

    • en

    • es

    Cable support systems - Complete catalogue

    Catalogue for cable trays, mesh cable trays, cable ladders, wide-span systems, vertical ladders, floor ducts, cable clamps, cable support troughs, rigid conduits, marine cable ladders, support systems, fastening accessories and more.

    PDF

    Choose languageChoose language

    Cable support systems - Complete catalogue

    Choose language to download

    • de

    • en

    Price list 2026 Building extension

    Valid from February 1st, 2026

    PDF

    Choose languageChoose language

    Price list 2026 Building extension

    Choose language to download

    • de

    • en

    Safe working load (Mesh cable tray G 35)

    Certificate, tested in accordance to DIN EN 61537

    PDF

    Choose languageChoose language

    Safe working load (Mesh cable tray G 35)

    Choose language to download

    • de

    • en

    Electrical conductivity (G 35 & GVE)

    Certificate, tested in accordance to DIN EN 61537

    PDF

    Choose languageChoose language

    Electrical conductivity (G 35 & GVE)

    Choose language to download

Load diagram
