UEBD RP E

UEBD RP E installation units are round dummy cover units with abutting edges. They can accommodate a maximum of three mounting boxes. They consist of height-adjustable mounting frames with a dummy insert cartridge and a rubber seal and are suitable for wet-cleaned rooms with office traffic loads. They are installed in assembly covers, floor sockets and raised or false floor openings. The components are made of stainless steel V2A and have a flat, blasted surface. They have an IP protection class of IP 54 in an unused condition, a max. load capacity of 4.00 kN, a levelling range of 55 mm and installation dimensions of 307 mm.
