RVB 60

Cable tray vertical bend, height = 60 mm

The cable tray vertical bend RVB 60 allows the direction of cable routing to be changed flexibly and vertically. It is inserted into the cable tray along with a REB cable tray end plate and bolted to the bottom and sides. The vertical bend RVB 60 is suitable for cable trays with sides 60 mm high. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RVB 60-05S
    Cable tray vertical bend RVB 60-10S
    height
    60 mm
    width
    50 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    1.902 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-10S
    Cable tray vertical bend RVB 60-10S
    height
    60 mm
    width
    100 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    2.076 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-20S
    Cable tray vertical bend RVB 60-20S
    height
    60 mm
    width
    200 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    2.426 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-30S
    Cable tray vertical bend RVB 60-30S
    height
    60 mm
    width
    300 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    2.776 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-40S
    Cable tray vertical bend RVB 60-40S
    height
    60 mm
    width
    400 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    3.124 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-50S
    Cable tray vertical bend RVB 60-50S
    height
    60 mm
    width
    500 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    3.474 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-60S
    Cable tray vertical bend RVB 60-60S
    height
    60 mm
    width
    600 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    3.822 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RVB 60-10F
    Cable tray vertical bend RVB 60-10F
    height
    60 mm
    width
    100 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    2.220 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-20F
    Cable tray vertical bend RVB 60-20F
    height
    60 mm
    width
    200 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    2.594 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-30F
    Cable tray vertical bend RVB 60-30F
    height
    60 mm
    width
    300 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    2.966 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-40F
    Cable tray vertical bend RVB 60-40F
    height
    60 mm
    width
    400 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    3.340 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-50F
    Cable tray vertical bend RVB 60-50F
    height
    60 mm
    width
    500 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    3.714 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RVB 60-60F
    Cable tray vertical bend RVB 60-60F
    height
    60 mm
    width
    600 mm
    radius
    300 mm
    Direction change
    rising/falling
    Angle
    var.
    Weight per storage unit
    4.088 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Details

  • Creates flexible vertical change of cable routing direction
