Cable tray bend, height = 110 mm

The cable tray bend RB45 110 allows the direction of cable routing to be changed horizontally by 45°. They are suitable for cable trays with sides 110 mm high and have integrated side connectors. The bend is inserted into the cable tray and bolted in place using a VB floor connector. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

RB45 110-10S
Cable tray bend 45°
height
110 mm
width
100 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.345 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-20S
Cable tray bend 45°
height
110 mm
width
200 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.646 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-30S
Cable tray bend 45°
height
110 mm
width
300 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
2.238 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-40S
Cable tray bend 45°
height
110 mm
width
400 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
2.705 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-50S
Cable tray bend 45°
height
110 mm
width
500 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
3.253 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-60S
Cable tray bend 45°
height
110 mm
width
600 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
3.868 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information

Steel, hot-dip galvanised

RB45 110-10F
Cable tray bend 45°
height
110 mm
width
100 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.443 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-20F
Cable tray bend 45°
height
110 mm
width
200 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.765 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-30F
Cable tray bend 45°
height
110 mm
width
300 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
2.399 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-40F
Cable tray bend 45°
height
110 mm
width
400 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
2.899 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-50F
Cable tray bend 45°
height
110 mm
width
500 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
3.485 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-60F
Cable tray bend 45°
height
110 mm
width
600 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
4.143 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information

Stainless steel, acc. to AISI 304 (BS 304S31)

RB45 110-10E
Cable tray bend 45°
height
110 mm
width
100 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.139 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-20E
Cable tray bend 45°
height
110 mm
width
200 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.442 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-30E
Cable tray bend 45°
height
110 mm
width
300 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
1.987 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-40E
Cable tray bend 45°
height
110 mm
width
400 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
2.456 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-50E
Cable tray bend 45°
height
110 mm
width
500 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
3.008 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information
RB45 110-60E
Cable tray bend 45°
height
110 mm
width
600 mm
Direction change
horizontal
Angle
45°
Weight per storage unit
3.644 kg
Geeignet für Funktionserhalt
Nein
Included accessories
More information

Details

Creates horizontal changes of the cable routing direction by 45°.
