RBD45

Cable tray bend cover

The cable tray bend covers RBD45 are suitable for RB45 cable tray bends and protect them from dirt and moisture. They snap into place and interlock with the side rails. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RBD45 10S
    Cable tray bend cover RBD45 10S
    width
    106 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.110 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 20S
    Cable tray bend cover RBD45 20S
    width
    206 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.245 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 30S
    Cable tray bend cover RBD45 30S
    width
    306 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.555 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 40S
    Cable tray bend cover RBD45 40S
    width
    406 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    1.005 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 50S
    Cable tray bend cover RBD45 50S
    width
    506 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    1.500 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 60S
    Cable tray bend cover RBD45 60S
    width
    606 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    1.995 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Steel, hot-dip galvanised

Article

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RBD45 10F
    Cable tray bend cover RBD45 10F
    width
    106 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.120 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 20F
    Cable tray bend cover RBD45 20F
    width
    206 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.265 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 30F
    Cable tray bend cover RBD45 30F
    width
    306 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.640 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 40F
    Cable tray bend cover RBD45 40F
    width
    406 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.980 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 50F
    Cable tray bend cover RBD45 50F
    width
    506 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    1.630 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 60F
    Cable tray bend cover RBD45 60F
    width
    606 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    2.175 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RBD45 10E
    Cable tray bend cover RBD45 10S
    width
    106 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.110 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 20E
    Cable tray bend cover RBD45 20S
    width
    206 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.260 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 30E
    Cable tray bend cover RBD45 30S
    width
    306 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.570 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 40E
    Cable tray bend cover RBD45 30S
    width
    406 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    0.880 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 50E
    Cable tray bend cover RBD45 30S
    width
    506 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    1.570 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBD45 60E
    Cable tray bend cover RBD45 30S
    width
    606 mm
    Direction change
    horizontal
    Angle
    45°
    Weight per storage unit
    2.130 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Protects the cable tray bend RB45 against external influences
  • Easy assembly without additional tools: Snap the cover onto the bend

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link
