RB 60

Cable tray bend, height = 60 mm

The cable tray bend RB 60 allows the direction of cable routing to be changed horizontally by 90°. They are suitable for cable trays with sides 60 mm high and have integrated side connectors. The bend is inserted into the cable tray and bolted in place using a VB floor connector. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

The magnetic shielding attenuation is 22 dB without the cover and 27 dB with the cover.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 60-05S
    Cable tray bend 90°
    height
    60 mm
    width
    50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.122 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-10S
    Cable tray bend 90°
    height
    60 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.760 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-15S
    Cable tray bend 90°
    height
    60 mm
    width
    150 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.963 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-20S
    Cable tray bend 90°
    height
    60 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.209 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-30S
    Cable tray bend 90°
    height
    60 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.878 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-40S
    Cable tray bend 90°
    height
    60 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.656 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-50S
    Cable tray bend 90°
    height
    60 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.588 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-60S
    Cable tray bend 90°
    height
    60 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.692 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 60-05F
    Cable tray bend 90°
    height
    60 mm
    width
    50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.597 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-10F
    Cable tray bend 90°
    height
    60 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.815 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-20F
    Cable tray bend 90°
    height
    60 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.296 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-30F
    Cable tray bend 90°
    height
    60 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.012 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-40F
    Cable tray bend 90°
    height
    60 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.844 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-50F
    Cable tray bend 90°
    height
    60 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.841 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-60F
    Cable tray bend 90°
    height
    60 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.022 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 60-05E
    Cable tray bend 90°
    height
    60 mm
    width
    50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.525 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-10E
    Cable tray bend 90°
    height
    60 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.685 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-20E
    Cable tray bend 90°
    height
    60 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.137 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-30E
    Cable tray bend 90°
    height
    60 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.796 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-40E
    Cable tray bend 90°
    height
    60 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.578 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-50E
    Cable tray bend 90°
    height
    60 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.517 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-60E
    Cable tray bend 90°
    height
    60 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.648 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 60-10E4
    Cable tray bend 90°
    height
    60 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.696 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-20E4
    Cable tray bend 90°
    height
    60 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.154 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-30E4
    Cable tray bend 90°
    height
    60 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.644 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-40E4
    Cable tray bend 90°
    height
    60 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.437 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-50E4
    Cable tray bend 90°
    height
    60 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.387 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 60-60E4
    Cable tray bend 90°
    height
    60 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.533 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Details
