Art.-Nr. RB 110-30S

Cable tray bend 90°

Cable tray bend, height = 110 mm

The cable tray bend RB 110 allows the direction of cable routing to be changed horizontally by 90°. They are suitable for cable trays with sides 110 mm high and have integrated side connectors. The bend is inserted into the cable tray and bolted in place using a VB floor connector. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Art.-Nr.
RB 110-30S
height
110 mm
width
300 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
2.833 kg
Geeignet für Funktionserhalt
Nein
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 110-10S
    Cable tray bend 90°
    height
    110 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.439 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-20S
    Cable tray bend 90°
    height
    110 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.953 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-30S
    Cable tray bend 90°
    height
    110 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.833 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-40S
    Cable tray bend 90°
    height
    110 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.677 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-50S
    Cable tray bend 90°
    height
    110 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.674 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-60S
    Cable tray bend 90°
    height
    110 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.843 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 110-10F
    Cable tray bend 90°
    height
    110 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.544 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-20F
    Cable tray bend 90°
    height
    110 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.094 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-30F
    Cable tray bend 90°
    height
    110 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.035 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-40F
    Cable tray bend 90°
    height
    110 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.938 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-50F
    Cable tray bend 90°
    height
    110 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.005 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-60F
    Cable tray bend 90°
    height
    110 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    6.256 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 110-10E
    Cable tray bend 90°
    height
    110 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.234 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-20E
    Cable tray bend 90°
    height
    110 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.751 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-30E
    Cable tray bend 90°
    height
    110 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.586 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-40E
    Cable tray bend 90°
    height
    110 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.434 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-50E
    Cable tray bend 90°
    height
    110 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.438 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-60E
    Cable tray bend 90°
    height
    110 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.635 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

Article

H

height

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RB 110-10E4
    Cable tray bend 90°
    height
    110 mm
    width
    100 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.252 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-20E4
    Cable tray bend 90°
    height
    110 mm
    width
    200 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.776 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-30E4
    Cable tray bend 90°
    height
    110 mm
    width
    300 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.621 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-40E4
    Cable tray bend 90°
    height
    110 mm
    width
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.481 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-50E4
    Cable tray bend 90°
    height
    110 mm
    width
    500 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.496 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information
  • RB 110-60E4
    Cable tray bend 90°
    height
    110 mm
    width
    600 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.710 kg
    Geeignet für Funktionserhalt
    Nein
    Included accessories
    More information

Details

  • Creates horizontal changes of the cable routing direction by 90°.
