RBDR

Cable tray cover with turnbuckles

The cable tray bend covers RBDR are suitable for RB cable tray bends 90° and protect them from dirt and moisture. They snap into place and interlock with the side rails and also have turning bolts for additional attachment to the bend. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. In this case, the twist lock alone is not sufficient as a retaining element. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RBDR 10S
    Cable tray bend cover with bar lock RBDR
    width
    106 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.160 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 20S
    Cable tray bend cover with bar lock RBDR
    width
    206 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.390 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 30S
    Cable tray bend cover with bar lock RBDR
    width
    306 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.910 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 40S
    Cable tray bend cover with bar lock RBDR
    width
    406 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.460 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 50S
    Cable tray bend cover with bar lock RBDR
    width
    506 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.650 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 60S
    Cable tray bend cover with bar lock RBDR
    width
    606 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.650 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Steel, hot-dip galvanised

Article

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RBDR 10F
    Cable tray bend cover with bar lock RBDR
    width
    106 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.180 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 20F
    Cable tray bend cover with bar lock RBDR
    width
    206 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.420 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 30F
    Cable tray bend cover with bar lock RBDR
    width
    306 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.980 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 40F
    Cable tray bend cover with bar lock RBDR
    width
    406 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.570 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 50F
    Cable tray bend cover with bar lock RBDR
    width
    506 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.840 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 60F
    Cable tray bend cover with bar lock RBDR
    width
    606 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.910 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

B

width

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RBDR 10E
    Cable tray bend cover with bar lock RBDR
    width
    106 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.180 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 20E
    Cable tray bend cover with bar lock RBDR
    width
    206 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.430 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 30E
    Cable tray bend cover with bar lock RBDR
    width
    306 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.930 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 40E
    Cable tray bend cover with bar lock RBDR
    width
    406 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.480 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 50E
    Cable tray bend cover with bar lock RBDR
    width
    506 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.680 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RBDR 60E
    Cable tray bend cover with bar lock RBDR
    width
    606 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.680 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Protects the cable tray bend RB 90° against external influences
  • Easy assembly without additional tools: Snap the cover onto the bend
  • Secured additionally by twist lock
