KLK

Cable duct with cover

KLK small ducts with covers are available in sendzimir hot-dip galvanised steel and have sides 30 to 60 mm high and are 30 to 60 mm wide. They are 3000 mm long.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

L

length

t

material thickness

G

Weight per storage unit

Geeignet für Funktionserhalt

  • KLK 30-03S
    Small ducts with covers
    height
    30 mm
    width
    30 mm
    length
    3000 mm
    material thickness
    1.00 mm
    Weight per storage unit
    3.670 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KLK 30-05S
    Small ducts with covers
    height
    30 mm
    width
    50 mm
    length
    3000 mm
    material thickness
    1.00 mm
    Weight per storage unit
    4.620 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KLK 40-04S
    Small ducts with covers
    height
    40 mm
    width
    40 mm
    length
    3000 mm
    material thickness
    1.00 mm
    Weight per storage unit
    4.620 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KLK 60-06S
    Small ducts with covers
    height
    60 mm
    width
    60 mm
    length
    3000 mm
    material thickness
    1.00 mm
    Weight per storage unit
    6.500 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Downloads

BIM- und CAD-Data

    BIM for BK floor ducts

    BIM data

    ZIP, 5.50 MB

    DownloadDownload
