Cable clamp for fastening to C profile rails

The H cable clamp with full-surface pressure trough can guide cables with a maximum diameter of 70 mm. It is suitable for attachment to C profile rails with a slot width of 16 mm. On request, a GW counter trough can be fitted for improved cable support. We provide components in various materials and surface finishes to ensure that various requirements for different areas of application are met.

The article is also available with lock nuts. This prevents the clamp from unintentionally coming loose. Lock nuts must be specified separately when ordering.

Articles with a diameter of 12 to 56 mm are also available in stainless steel with material no. 1.4571/1.4404 (V4A).

Get in touchDownload datasheet

Variants

steel, zinc plated

Article

Hmax

maximum height

D

clamping range

M

torque

cables

max. number of cables

G

Weight per storage unit

  • 12 H
    Cable clamp 12 H
    maximum height
    41 mm
    clamping range
    8 - 12 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.028 kg
    More information
  • 16 H
    Cable clamp 16 H
    maximum height
    46 mm
    clamping range
    12 - 16 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.032 kg
    More information
  • 20 H
    Cable clamp 20 H
    maximum height
    50 mm
    clamping range
    16 - 20 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.036 kg
    More information
  • 24 H
    Cable clamp 24 H
    maximum height
    54 mm
    clamping range
    20 - 24 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.039 kg
    More information
  • 28 H
    Cable clamp 28 H
    maximum height
    58 mm
    clamping range
    24 - 28 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.044 kg
    More information
  • 32 H
    Cable clamp 32 H
    maximum height
    63 mm
    clamping range
    28 - 32 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.053 kg
    More information
  • 36 H
    Cable clamp 36 H
    maximum height
    67 mm
    clamping range
    32 - 36 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.057 kg
    More information
  • 40 H
    Cable clamp 40 H
    maximum height
    71 mm
    clamping range
    36 - 40 mm
    torque
    2 Nm
    max. number of cables
    1
    Weight per storage unit
    0.062 kg
    More information
  • 44 H
    Cable clamp 44 H
    maximum height
    81 mm
    clamping range
    40 - 44 mm
    torque
    4 Nm
    max. number of cables
    1
    Weight per storage unit
    0.086 kg
    More information
  • 48 H
    Cable clamp 48 H
    maximum height
    85 mm
    clamping range
    44 - 48 mm
    torque
    4 Nm
    max. number of cables
    1
    Weight per storage unit
    0.095 kg
    More information
  • 52 H
    Cable clamp 52 H
    maximum height
    90 mm
    clamping range
    48 - 52 mm
    torque
    4 Nm
    max. number of cables
    1
    Weight per storage unit
    0.105 kg
    More information
  • 56 H
    Cable clamp 56 H
    maximum height
    94 mm
    clamping range
    52 - 56 mm
    torque
    4 Nm
    max. number of cables
    1
    Weight per storage unit
    0.109 kg
    More information
