BKDR

Floor duct cover with turning bolts

The BKDR floor duct cover is placed on top of the floor duct and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the floor duct and 1000, 1500 or 3000 mm long. The floor duct cover is made of sendzimir hot-dip galvanised steel and is not embossed. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. The covers are placed on top of the floor duct. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

L

length

t

material thickness

Pmax

maximum load

G

Weight per storage unit

Geeignet für Funktionserhalt

  • BKDR 1-10S
    Floor duct cover, length 1m,
    width
    100 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    2.090 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1-15S
    Floor duct cover, length 1m,
    width
    150 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    2.870 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1-20S
    Floor duct cover, length 1m,
    width
    200 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    3.660 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1-30S
    Floor duct cover, length 1m,
    width
    300 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    5.230 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1-40S
    Floor duct cover, length 1m,
    width
    400 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    6.800 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1-50S
    Floor duct cover, length 1m,
    width
    500 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    8.370 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1-60S
    Floor duct cover, length 1m,
    width
    600 mm
    length
    1000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    9.940 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-10S
    Floor duct cover, length 1.5m,
    width
    100 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    3.090 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-15S
    Floor duct cover, length 1.5m,
    width
    150 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    4.270 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-20S
    Floor duct cover, length 1.5m,
    width
    200 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    5.450 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-30S
    Floor duct cover, length 1.5m,
    width
    300 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    7.800 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-40S
    Floor duct cover, length 1.5m,
    width
    400 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    10.160 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-50S
    Floor duct cover, length 1.5m,
    width
    500 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    12.510 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 1.5-60S
    Floor duct cover, length 1.5m,
    width
    600 mm
    length
    1500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    14.870 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 10S
    Floor duct cover
    width
    100 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    6.210 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 15S
    Floor duct cover
    width
    150 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    8.560 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 20S
    Floor duct cover
    width
    200 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    10.930 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 30S
    Floor duct cover
    width
    300 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    15.630 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 40S
    Floor duct cover
    width
    400 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    20.340 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 50S
    Floor duct cover
    width
    500 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    25.050 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKDR 60S
    Floor duct cover
    width
    600 mm
    length
    3000 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    29.760 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Loadable up to 5 kN
  • Easy assembly

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link
