BKDSL

Floor duct cover protection strip

The BKDSL floor duct cover protection strip is used to cover the walk-on floor ducts seamlessly at the point where covers meet. This protects them against flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the floor duct and is made of sendzimir hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

G

Weight per storage unit

  • BKDSL 10S
    Floor duct cover protection strip
    width
    100 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.026 kg
    More information
  • BKDSL 15S
    Floor duct cover protection strip
    width
    150 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.040 kg
    More information
  • BKDSL 20S
    Floor duct cover protection strip
    width
    200 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.053 kg
    More information
  • BKDSL 30S
    Floor duct cover protection strip
    width
    300 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.079 kg
    More information
  • BKDSL 40S
    Floor duct cover protection strip
    width
    400 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.106 kg
    More information
  • BKDSL 50S
    Floor duct cover protection strip
    width
    500 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.132 kg
    More information
  • BKDSL 60S
    Floor duct cover protection strip
    width
    600 mm
    material thickness
    0.75 mm
    Weight per storage unit
    0.159 kg
    More information

Details

  • Seamless covering of walk-on floor ducts

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Downloads

BIM- und CAD-Data

    BIM for BK floor ducts

    BIM data

    ZIP, 5.50 MB

    DownloadDownload
