BKDU 100

Floor duct cover support, height = 100 mm

The BKDU 100 floor duct cover support provides additional support for the covers. It is placed in the floor duct with the open end facing downwards. The cover support is 200 to 600 mm wide corresponding to the floor duct, 100 mm high and is made of hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

B

width

t

material thickness

G

Weight per storage unit

  • BKDU 100-20F
    Floor duct cover support
    height
    100 mm
    width
    200 mm
    material thickness
    2.00 mm
    Weight per storage unit
    0.433 kg
    More information
  • BKDU 100-30F
    Floor duct cover support
    height
    100 mm
    width
    300 mm
    material thickness
    2.00 mm
    Weight per storage unit
    0.550 kg
    More information
  • BKDU 100-40F
    Floor duct cover support
    height
    100 mm
    width
    400 mm
    material thickness
    2.00 mm
    Weight per storage unit
    0.668 kg
    More information
  • BKDU 100-50F
    Floor duct cover support
    height
    100 mm
    width
    500 mm
    material thickness
    2.00 mm
    Weight per storage unit
    0.786 kg
    More information
  • BKDU 100-60F
    Floor duct cover support
    height
    100 mm
    width
    600 mm
    material thickness
    2.00 mm
    Weight per storage unit
    0.903 kg
    More information
