Snap-in ladder set for stainless steel unit, 3x, round
UGEAR components are snap-in ladder sets for accommodating max. 3 mounting boxes. The sets consist of two individual snap-in ladders that are attached to the frame of the installation units using suitable bolts. They are suitable for mounting on round stainless steel cartridges with cable or tube outlets. The products are made from sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346 and have VDE/TÜV certification in accordance with DIN EN 50085. They are 190 mm wide, 55 or 84 mm high and have a locking range of 25 or 35 mm.
H
height
B
width
mounting box
maximum number of installable device casings
G
Weight per storage unit
de
en
Valid from February 1st, 2025, updated version from 31/03/2025.
de
Declaration
PDF, 106.06 KB
DownloadDownload
de
en
Installation equipment for electric cables and circuits
de
en
Technical Information
de
en
Catalogue
de
en
Notice for installation units
de
en
Certificate
BIM Data
ZIP, 13.12 MB
DownloadDownloadAnzahl:
