Mounting board, audio/video technology
UDEP KM components are installation boards from the underfloor system range. The boards are bolted into data device carriers where they are used to accommodate a connection panel for audio or video technology of the type konnect 50 alu/50 steel made by Kindermann. The installation boards are made of aluminium with a black coating on one side and have the installation dimensions of E1 23 mm and E2 38 mm.
H
height
B
width
data jacks
Max. number of installable data jacks
E1
fitting dimension E1
E2
fitting dimension E2
colour
color
G
Weight per storage unit
