RKD

Cable tray crossing cover

The cable tray crossing covers RKD are suitable for RK cable tray crossings and protect them from dirt and moisture. They snap into place and interlock with the side rails. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

G

Weight per storage unit

  • RKD 10S
    Cable tray cross-piece cover RKD 10S
    width
    106 mm
    Weight per storage unit
    0.260 kg
    More information
  • RKD 20S
    Cable tray cross-piece cover RKD 20S
    width
    206 mm
    Weight per storage unit
    0.570 kg
    More information
  • RKD 30S
    Cable tray cross-piece cover RKD 30S
    width
    306 mm
    Weight per storage unit
    1.330 kg
    More information
  • RKD 40S
    Cable tray cross-piece cover RKD 40S
    width
    406 mm
    Weight per storage unit
    2.050 kg
    More information
  • RKD 50S
    Cable tray cross-piece cover RKD 50S
    width
    506 mm
    Weight per storage unit
    3.670 kg
    More information
  • RKD 60S
    Cable tray cross-piece cover RKD 60S
    width
    606 mm
    Weight per storage unit
    4.980 kg
    More information

Steel, hot-dip galvanised

Article

B

width

G

Weight per storage unit

  • RKD 10F
    Cable tray cross-piece cover RKD 10F
    width
    106 mm
    Weight per storage unit
    0.270 kg
    More information
  • RKD 20F
    Cable tray cross-piece cover RKD 20F
    width
    206 mm
    Weight per storage unit
    0.610 kg
    More information
  • RKD 30F
    Cable tray cross-piece cover RKD 30F
    width
    306 mm
    Weight per storage unit
    1.420 kg
    More information
  • RKD 40F
    Cable tray cross-piece cover RKD 40F
    width
    406 mm
    Weight per storage unit
    2.190 kg
    More information
  • RKD 50F
    Cable tray cross-piece cover RKD 50F
    width
    506 mm
    Weight per storage unit
    3.930 kg
    More information
  • RKD 60F
    Cable tray cross-piece cover RKD 60F
    width
    606 mm
    Weight per storage unit
    5.330 kg
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

B

width

G

Weight per storage unit

  • RKD 10E
    Cable tray cross-piece cover RKD 10E
    width
    106 mm
    Weight per storage unit
    0.270 kg
    More information
  • RKD 20E
    Cable tray cross-piece cover RKD 20E
    width
    206 mm
    Weight per storage unit
    0.610 kg
    More information
  • RKD 30E
    Cable tray cross-piece cover RKD 30E
    width
    306 mm
    Weight per storage unit
    1.330 kg
    More information
  • RKD 40E
    Cable tray cross-piece cover RKD 40E
    width
    406 mm
    Weight per storage unit
    2.070 kg
    More information
  • RKD 50E
    Cable tray cross-piece cover RKD 50E
    width
    506 mm
    Weight per storage unit
    3.700 kg
    More information
  • RKD 60E
    Cable tray cross-piece cover RKD 60E
    width
    606 mm
    Weight per storage unit
    5.000 kg
    More information

Details

  • Protects the cable tray crossing RK from external influences
  • Easy assembly: snap the cover into place on the cable tray crossing

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Downloads

BIM- und CAD-Data

    BIM for cable trays

    Bim data

    ZIP, 9.58 MB

    DownloadDownload
