RID

RID

Installation cable tray cover

The installation cable tray covers RID are suitable for installation cable trays and protect them from dirt and moisture. They snap into place and interlock with the side rails. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. The cover is 50 to 300 mm wide corresponding to the channel and has a standard length of 3000 mm. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

RID 05S
Cable installation tray cover RID 05S
width
56 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
1.520 kg
Geeignet für Funktionserhalt
Nein
More information
RID 10S
Cable installation tray cover RID 10S
width
106 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
2.400 kg
Geeignet für Funktionserhalt
Nein
More information
RID 15S
Cable installation tray cover RID 15S
width
156 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
3.290 kg
Geeignet für Funktionserhalt
Nein
More information
RID 20S
Cable installation tray cover RID 20S
width
206 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
4.170 kg
Geeignet für Funktionserhalt
Nein
More information
RID 30S
Cable installation tray cover RID 30S
width
306 mm
length
3000 mm
material thickness
1.00 mm
Weight per storage unit
7.910 kg
Geeignet für Funktionserhalt
Nein
More information

Steel, hot-dip galvanised

RID 05F
Cable installation tray cover RID 05F
width
56 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
1.630 kg
Geeignet für Funktionserhalt
Nein
More information
RID 10F
Cable installation tray cover RID 10F
width
106 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
2.570 kg
Geeignet für Funktionserhalt
Nein
More information
RID 15F
Cable installation tray cover RID 15F
width
156 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
3.520 kg
Geeignet für Funktionserhalt
Nein
More information
RID 20F
Cable installation tray cover RID 20F
width
206 mm
length
3000 mm
material thickness
0.75 mm
Weight per storage unit
4.460 kg
Geeignet für Funktionserhalt
Nein
More information
RID 30F
Cable installation tray cover RID 30F
width
306 mm
length
3000 mm
material thickness
1.00 mm
Weight per storage unit
8.470 kg
Geeignet für Funktionserhalt
Nein
More information

Stainless steel, acc. to AISI 304 (BS 304S31)

RID 05E
Cable installation tray cover RID 05S
width
56 mm
length
3000 mm
material thickness
0.80 mm
Weight per storage unit
1.501 kg
Geeignet für Funktionserhalt
Nein
More information
RID 10E
Cable installation tray cover RID 10S
width
106 mm
length
3000 mm
material thickness
0.80 mm
Weight per storage unit
2.580 kg
Geeignet für Funktionserhalt
Nein
More information
RID 15E
Cable installation tray cover RID 15S
width
156 mm
length
3000 mm
material thickness
0.80 mm
Weight per storage unit
3.530 kg
Geeignet für Funktionserhalt
Nein
More information
RID 20E
Cable installation tray cover RID 20S
width
206 mm
length
3000 mm
material thickness
0.80 mm
Weight per storage unit
4.470 kg
Geeignet für Funktionserhalt
Nein
More information
RID 30E
Cable installation tray cover RID 30S
width
306 mm
length
3000 mm
material thickness
1.00 mm
Weight per storage unit
7.960 kg
Geeignet für Funktionserhalt
Nein
More information

Details

Protects the cable tray from external influences
Easy assembly without additional tools: Snap the cover in place on the cable tray

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link

Heinze.de

Tender texts for this product

Open Link

Accessories

RD-SW
Cable tray storm protection bracket
