RIBDS

Installation cable tray bend cover, heavy

The installation cable tray bend covers RIBDS 90 are suitable for RIB installation cable tray bends 90 and protect them from dirt and moisture. They snap into place and interlock with the side rails. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. The cover is made of sendzimir hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • RIBDS 05S
    Cable tray bend cover RIBDS 05S
    width
    50 mm
    material thickness
    1.50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.108 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RIBDS 10S
    Cable tray bend cover RBD 10S
    width
    100 mm
    material thickness
    1.50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.248 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RIBDS 20S
    Cable tray bend cover RBD 10S
    width
    200 mm
    material thickness
    1.50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.671 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • RIBDS 30S
    Cable tray bend cover RBD 10S
    width
    300 mm
    material thickness
    1.50 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.281 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Protects the installation cable tray bend RIB 90° against external influences
  • Heavy-duty version
  • Easy assembly without additional tools: Snap the cover onto the bend
