RG 60

Cable tray, perforated, height = 60 mm, circuit integrity systems, system-specific

No stepping
Fire protection
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

L

length

t

material thickness

QSK

distributed load control cable

BV

No stepping

A

cross section area

Suitable for functional integrity

Suitable for escape route installations

G

Weight per storage unit

  • RG 60-10S
    Cable tray
    height
    60 mm
    width
    100 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.09 kN/m
    No stepping
    Yes (1)
    cross section area
    57 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Ja
    Weight per storage unit
    4.300 kg
    More information
  • RG 60-20S
    Cable tray
    height
    60 mm
    width
    200 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.17 kN/m
    No stepping
    Yes (1)
    cross section area
    117 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Ja
    Weight per storage unit
    5.800 kg
    More information
  • RG 60-30S
    Cable tray
    height
    60 mm
    width
    300 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.26 kN/m
    No stepping
    Yes (1)
    cross section area
    177 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Ja
    Weight per storage unit
    7.400 kg
    More information
  • RG 60-40S
    Cable tray
    height
    60 mm
    width
    400 mm
    length
    3000 mm
    material thickness
    0.88 mm
    distributed load control cable
    0.34 kN/m
    No stepping
    Yes (1)
    cross section area
    237 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Ja
    Weight per storage unit
    10.600 kg
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

L

length

t

material thickness

QSK

distributed load control cable

BV

No stepping

A

cross section area

Suitable for functional integrity

Suitable for escape route installations

G

Weight per storage unit

  • RG 60-10F
    Cable tray
    height
    60 mm
    width
    100 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.09 kN/m
    No stepping
    Yes (1)
    cross section area
    57 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Nein
    Weight per storage unit
    4.800 kg
    More information
  • RG 60-20F
    Cable tray
    height
    60 mm
    width
    200 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.17 kN/m
    No stepping
    Yes (1)
    cross section area
    117 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Nein
    Weight per storage unit
    6.500 kg
    More information
  • RG 60-30F
    Cable tray
    height
    60 mm
    width
    300 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.26 kN/m
    No stepping
    Yes (1)
    cross section area
    177 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Nein
    Weight per storage unit
    8.300 kg
    More information
  • RG 60-40F
    Cable tray
    height
    60 mm
    width
    400 mm
    length
    3000 mm
    material thickness
    0.88 mm
    distributed load control cable
    0.34 kN/m
    No stepping
    Yes (1)
    cross section area
    237 cm2
    Suitable for functional integrity
    Ja
    Suitable for escape route installations
    Nein
    Weight per storage unit
    11.700 kg
    More information

Details

    Tender texts

    Ausschreiben.de

    Tender texts for this product

    Open Link
    Heinze.de

    Tender texts for this product

    Open Link

    Downloads

      • de

      P-MPA-E-15-019 - KDU57 - Functional maintenance certificate

      General building authority test certificate
      DIN 4102-12
      Cable manufacturers: Dätwyler, Eupen, Leoni Studer, Prysmian, Nexans
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: ≤ 20 kg/m
      Fastening distance: ≤ 1.5 m
      Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
      Period of validity: 09.10.2026

      PDF (10.27 MB)

      DownloadDownload

      • de

      P-MPA-E-14-010 - KDU57/KDU 60 - Functional maintenance certificate

      General building authority test certificate
      DIN 4102-12
      Cable manufacturer: Kabelwerke Eupen AG
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: 20 kg/m
      Fastening distance: ≤ 1.5 m
      Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
      Period of validity: 23/07/2029

      PDF (4.94 MB)

      DownloadDownload

      • de

      P-MPA-E-16-013 - KDU57/KDU 60 - Functional maintenance certificate

      General building authority test certificate
      DIN 4102-12
      Cable manufacturer: Studer Cables AG
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: 20 kg/m
      Fastening distance: ≤ 1.5 m
      Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
      Period of validity: 30.08.2027

      PDF (7.84 MB)

      DownloadDownload

      • de

      P-MPA-E-16-007 - KDU60 - Functional maintenance certificate

      DIN 4102-12
      Cable manufacturer: Dätwyler
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: ≤ 30 kg/m
      Fastening distance: ≤ 1.5 m
      Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
      Validity period: 01.02.2027

      PDF (8.13 MB)

      DownloadDownload

      • de

      MPABS-2400990 - Mixes cable installations - Fire protection statement

      DIN 4102-12
      Fire resistance duration: F30; F60; F90
      Functional integrity classes: E30; E60; F90
      Period of validity: 10.06.2029

      PDF (195.29 KB)

      DownloadDownload

      • de

      2104/681/23 - Fire protection assessment

      False ceiling installation, escape route installation, MLAR, LAR
      Fire resistance duration: F30
      Fire resistance: 30 minutes
      Fastening distance: ≤ 1.5 m
      Period of validity: 18.12.2028

      PDF (5.77 MB)

      DownloadDownload

      • de

      GA-2017/068 - Expert statement

      DIN 4102-12
      Fire protection fastening on load-bearing timber components
      Fire resistance duration: F30; F60
      Functional maintenance classes: E30; E60
      Cable load: ≤ 10 kg/m, ≤ 20 kg/m, ≤ 30 kg/m
      Mounting distance: ≤ 1.5 m
      Period of validity: 22/08/2027

      PDF (1.49 MB)

      DownloadDownload

      • de

      GA-2025-036 - Mixed cable installation assembly of floor connectors - Expert statement

      DIN 4102-12
      Fire resistance duration: F30; F60; F90
      Functional integrity classes: E30; E60; F90
      Period of validity: 09.05.2030

      PDF (186.69 KB)

      DownloadDownload
