RGV-BS 60

Cable tray side connector, height = 45 mm, maintenance of function

Fire protection

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

RGV-BS 60S
Cable tray coupler, fire prevention
height
45 mm
length
190 mm
Weight per storage unit
0.150 kg
Included accessories
More information

Steel, hot-dip galvanised

RGV-BS 60F
Cable tray coupler, fire prevention
height
45 mm
length
190 mm
Weight per storage unit
0.156 kg
Included accessories
More information

Details

Tender texts

Ausschreiben.de

Tender texts for this product

Heinze.de

Tender texts for this product

Downloads

de
P-MPA-E-15-019 - KDU57 - Functional maintenance certificate
General building authority test certificate
DIN 4102-12
Cable manufacturers: Dätwyler, Eupen, Leoni Studer, Prysmian, Nexans
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: ≤ 20 kg/m
Fastening distance: ≤ 1.5 m
Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
Period of validity: 09.10.2026
PDF (10.27 MB)
DownloadDownload

de
P-MPA-E-14-010 - KDU57/KDU 60 - Functional maintenance certificate
General building authority test certificate
DIN 4102-12
Cable manufacturer: Kabelwerke Eupen AG
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: 20 kg/m
Fastening distance: ≤ 1.5 m
Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
Period of validity: 23/07/2029
PDF (4.94 MB)
DownloadDownload

de
P-MPA-E-16-013 - KDU57/KDU 60 - Functional maintenance certificate
General building authority test certificate
DIN 4102-12
Cable manufacturer: Studer Cables AG
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: 20 kg/m
Fastening distance: ≤ 1.5 m
Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
Period of validity: 30.08.2027
PDF (7.84 MB)
DownloadDownload

de
P-MPA-E-16-007 - KDU60 - Functional maintenance certificate
DIN 4102-12
Cable manufacturer: Dätwyler
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: ≤ 30 kg/m
Fastening distance: ≤ 1.5 m
Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
Validity period: 01.02.2027
PDF (8.13 MB)
DownloadDownload

de
MPABS-2402543 - Fire protection statement
DIN 4102-12
Standardised supporting structure: Cable trays
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: ≤ 10 kg/m
Fastening distance: ≤ 1.2 m
Period of validity: 15.01.2030
PDF (11.03 MB)
DownloadDownload

de
2104/681/23 - Fire protection assessment
False ceiling installation, escape route installation, MLAR, LAR
Fire resistance duration: F30
Fire resistance: 30 minutes
Fastening distance: ≤ 1.5 m
Period of validity: 18.12.2028
PDF (5.77 MB)
DownloadDownload

de
GA-2017/068 - Expert statement
DIN 4102-12
Fire protection fastening on load-bearing timber components
Fire resistance duration: F30; F60
Functional maintenance classes: E30; E60
Cable load: ≤ 10 kg/m, ≤ 20 kg/m, ≤ 30 kg/m
Mounting distance: ≤ 1.5 m
Period of validity: 22/08/2027
PDF (1.49 MB)
DownloadDownload

de
en
Price list 2026 Building extension
Valid from February 1st, 2026
PDF
Choose languageChoose language
Price list 2026 Building extension
Choose language to download
German (45.28 MB)
English (45.22 MB)

de
en

Price list 2026 Building extension (Excel)

Valid from February 1, 2026

ZIP

Choose languageChoose language

Included accessories
