Art.-Nr. KTW-A 8

Cable support trough KTW-A 8

Cable support trough, Ø 100 mm

The cable support tray KTW-A is used for routing cables on walls in a space-saving manner. It is available in widths from 56 to 138 mm and allowing for cable diameters from 40 to 120 mm. It is attached to profile rails in one or more tiers. Support intervals of 700 to 1000 mm must be observed when routing the cables. The cable support tray KTW-A is made of hot-dip galvanised steel.

Art.-Nr.
KTW-A 8
width
96 mm
Diameter (mm)
80 mm
maximum load
0.7 kN
Weight per storage unit
0.490 kg
Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

B

width

D

Diameter (mm)

Pmax

maximum load

G

Weight per storage unit

Included accessories
  • KTW-A 4
    Cable support trough KTW-A 4
    width
    56 mm
    Diameter (mm)
    40 mm
    maximum load
    1 kN
    Weight per storage unit
    0.323 kg
    Included accessories
    More information
  • KTW-A 5
    Cable support trough KTW-A 5
    width
    66 mm
    Diameter (mm)
    50 mm
    maximum load
    0.92 kN
    Weight per storage unit
    0.350 kg
    Included accessories
    More information
  • KTW-A 6
    Cable support trough KTW-A 6
    width
    76 mm
    Diameter (mm)
    60 mm
    maximum load
    0.85 kN
    Weight per storage unit
    0.377 kg
    Included accessories
    More information
  • KTW-A 7
    Cable support trough KTW-A 7
    width
    86 mm
    Diameter (mm)
    70 mm
    maximum load
    0.77 kN
    Weight per storage unit
    0.470 kg
    Included accessories
    More information
  • KTW-A 8
    Cable support trough KTW-A 8
    width
    96 mm
    Diameter (mm)
    80 mm
    maximum load
    0.7 kN
    Weight per storage unit
    0.490 kg
    Included accessories
    More information
  • KTW-A 10
    Cable support trough KTW-A 10
    width
    118 mm
    Diameter (mm)
    100 mm
    maximum load
    0.62 kN
    Weight per storage unit
    0.552 kg
    Included accessories
    More information
  • KTW-A 12
    Cable support trough KTW-A 12
    width
    138 mm
    Diameter (mm)
    120 mm
    maximum load
    0.42 kN
    Weight per storage unit
    0.612 kg
    Included accessories
    More information
