KD

Plastic dowels

The plastic plug KD is made of polyamide and is suitable for pre-insertion and through-insertion of wood and chipboard screws. It has an outer diameter D (= drill core diameter) of 8 to 14 mm and an inner diameter ø (= wood screw diameter) of 6 to 12 mm. The minimum drilling depth must be 55 to 90 mm. The manufacturer's specifications must be observed.

Get in touchDownload datasheet

Variants

polyamide

Article

D

Diameter (mm)

Ø

thread diameter

Lmin

min. borehole depth

G

Weight per storage unit

  • KD 6
    Plastic dowel KD 6
    Diameter (mm)
    8 mm
    thread diameter
    6 mm
    min. borehole depth
    55 mm
    Weight per storage unit
    0.001 kg
    More information
  • KD 8
    Plastic dowel KD 8
    Diameter (mm)
    10 mm
    thread diameter
    8 mm
    min. borehole depth
    70 mm
    Weight per storage unit
    0.002 kg
    More information
  • KD 10
    Plastic dowel KD 10
    Diameter (mm)
    12 mm
    thread diameter
    10 mm
    min. borehole depth
    80 mm
    Weight per storage unit
    0.004 kg
    More information
  • KD 12
    Plastic dowel KD 12
    Diameter (mm)
    14 mm
    thread diameter
    12 mm
    min. borehole depth
    95 mm
    Weight per storage unit
    0.006 kg
    More information
