BKVBDR

Floor duct bend cover, variable with turnbuckles

The BKVBDR variable floor duct cover is placed on top of the floor duct bend BKVB and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the bend. The floor duct bend cover is made of sendzimir hot-dip galvanised steel and is not embossed. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

Pmax

maximum load

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • BKVBDR 10S
    Floor duct bend cover, variable,
    width
    100 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    0.350 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKVBDR 15S
    Floor duct bend cover, variable,
    width
    150 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    0.570 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKVBDR 20S
    Floor duct bend cover, variable,
    width
    200 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    0.850 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKVBDR 30S
    Floor duct bend cover, variable,
    width
    300 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    1.600 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKVBDR 40S
    Floor duct bend cover, variable,
    width
    400 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    2.590 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKVBDR 50S
    Floor duct bend cover, variable,
    width
    500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    3.830 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKVBDR 60S
    Floor duct bend cover, variable,
    width
    600 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    var.
    Weight per storage unit
    5.310 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Loadable up to 5 kN
  • Easy assembly
