BKVAADR-RHP

Floor duct add-on tee cover, variable with anti-slip embossing

The BKVAADR-RHP variable floor duct attachment branch cover is placed on top of the BKVAA floor duct attachment branch and protects cables and supply lines from flying sparks and other mechanical effects. It is 100 to 600 mm wide corresponding to the attachment branch. The floor duct attachment branch cover is made of sendzimir hot-dip galvanised steel with slip resistance class R11. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Slip resistance and slip resistance according to: DIN EN 16165
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

Pmax

maximum load

Slip resistance and slip resistance according to

G

Weight per storage unit

  • BKVAADR-RHP 10S
    Floor duct attachment branch cover, variable,
    width
    100 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.350 kg
    More information
  • BKVAADR-RHP 15S
    Floor duct attachment branch cover, variable,
    width
    150 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.490 kg
    More information
  • BKVAADR-RHP 20S
    Floor duct attachment branch cover, variable,
    width
    200 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.740 kg
    More information
  • BKVAADR-RHP 30S
    Floor duct attachment branch cover, variable,
    width
    300 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    1.220 kg
    More information
  • BKVAADR-RHP 40S
    Floor duct attachment branch cover, variable,
    width
    400 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    1.930 kg
    More information
  • BKVAADR-RHP 50S
    Floor duct attachment branch cover, variable,
    width
    500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    2.820 kg
    More information
  • BKVAADR-RHP 60S
    Floor duct attachment branch cover, variable,
    width
    600 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    3.890 kg
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Slip resistance and slip resistance according to: DIN EN 16165
  • Loadable up to 5.00 kN
  • Non-slip embossing R11
  • Easy assembly
