BKGLDR

Floor duct bend cover, mitre cut on left and turnbuckles

The BKGLDR floor duct cover with a mitre cut on the left is placed on top of the BKGL floor duct branch and protects cables and supply lines from flying sparks and other mechanical effects. It is 100 to 600 mm wide corresponding to the branch. The floor duct cover is made of sendzimir hot-dip galvanised steel and is not embossed. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

Pmax

maximum load

G

Weight per storage unit

  • BKGLDR 10S
    Floor duct branch cover with mitre
    width
    100 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.634 kg
    More information
  • BKGLDR 15S
    Floor duct branch cover with mitre
    width
    150 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.930 kg
    More information
  • BKGLDR 20S
    Floor duct branch cover with mitre
    width
    200 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    1.263 kg
    More information
  • BKGLDR 30S
    Floor duct branch cover with mitre
    width
    300 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    2.040 kg
    More information
  • BKGLDR 40S
    Floor duct branch cover with mitre
    width
    400 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    2.990 kg
    More information
  • BKGLDR 50S
    Floor duct branch cover with mitre
    width
    500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    4.090 kg
    More information
  • BKGLDR 60S
    Floor duct branch cover with mitre
    width
    600 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    5.350 kg
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Loadable up to 5 kN
  • Easy assembly

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link
