BKBRDR

Floor duct bend cover with radius and turnbuckles

The BKBRDR floor duct bend cover is placed on top of the floor duct bend BKBR and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the bend. The floor duct bend cover is made of sendzimir hot-dip galvanised steel and is not embossed. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

Pmax

maximum load

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • BKBRDR 10S
    Floor duct bend cover with curve
    width
    100 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    0.990 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBRDR 15S
    Floor duct bend cover with curve
    width
    150 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    1.480 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBRDR 20S
    Floor duct bend cover with curve
    width
    200 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.050 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBRDR 30S
    Floor duct bend cover with curve
    width
    300 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.420 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBRDR 40S
    Floor duct bend cover with curve
    width
    400 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.110 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBRDR 50S
    Floor duct bend cover with curve
    width
    500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    7.110 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBRDR 60S
    Floor duct bend cover with curve
    width
    600 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    9.430 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Loadable up to 5 kN
  • Easy assembly
