BKBDR-RHP

Floor duct bend cover with anti-slip embossing

The floor duct bend cover BKBDR-RHP is placed on top of the BKB floor duct bend and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the bend. The floor duct bend cover is made of sendzimir hot-dip galvanised steel with slip resistance class R11. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Slip resistance and slip resistance according to: DIN EN 16165
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

Pmax

maximum load

direction

Direction change

W

Angle

Slip resistance and slip resistance according to

G

Weight per storage unit

Geeignet für Funktionserhalt

  • BKBDR-RHP 10S
    Floor duct bend cover
    width
    100 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.360 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBDR-RHP 15S
    Floor duct bend cover
    width
    150 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.650 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBDR-RHP 20S
    Floor duct bend cover
    width
    200 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.940 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBDR-RHP 30S
    Floor duct bend cover
    width
    300 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    1.750 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBDR-RHP 40S
    Floor duct bend cover
    width
    400 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    2.840 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBDR-RHP 50S
    Floor duct bend cover
    width
    500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    4.180 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • BKBDR-RHP 60S
    Floor duct bend cover
    width
    600 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Direction change
    horizontal
    Angle
    90°
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    5.780 kg
    Geeignet für Funktionserhalt
    Nein
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Slip resistance and slip resistance according to: DIN EN 16165
  • Loadable up to 5.00 kN
  • Non-slip embossing R11
  • Easy assembly
