BKADR-WZB AL

Floor duct tee cover made of aluminium diamond plate

The floor duct branch cover BKADR-WZB AL is placed on top of the BKA floor duct branch and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the branch. The floor duct branch cover is made of aluminium diamond plate with slip resistance class R9. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 3.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Slip resistance and slip resistance according to: DIN EN 16165
Get in touchDownload datasheet

Variants

aluminium

Article

B

width

t

material thickness

Pmax

maximum load

Slip resistance and slip resistance according to

G

Weight per storage unit

  • BKADR-WZB 10AL
    Floor duct branch cover
    width
    100 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.330 kg
    More information
  • BKADR-WZB 15AL
    Floor duct branch cover
    width
    150 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.500 kg
    More information
  • BKADR-WZB 20AL
    Floor duct branch cover
    width
    200 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    0.710 kg
    More information
  • BKADR-WZB 30AL
    Floor duct branch cover
    width
    300 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    1.220 kg
    More information
  • BKADR-WZB 40AL
    Floor duct branch cover
    width
    400 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    1.870 kg
    More information
  • BKADR-WZB 50AL
    Floor duct branch cover
    width
    500 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    2.670 kg
    More information
  • BKADR-WZB 60AL
    Floor duct branch cover
    width
    600 mm
    material thickness
    2.50 mm
    maximum load
    3.00 kN
    Slip resistance and slip resistance according to
    DIN EN 16165
    Weight per storage unit
    3.620 kg
    More information

Details

  • Load requirements according to: EN 50085-2-2
  • Slip resistance and slip resistance according to: DIN EN 16165
  • Loadable up to 3.00 kN
  • Non-slip embossing R9
  • Easy assembly
