BKAADR

Floor duct add-on tee cover with turnbuckles

The BKAADR floor duct attachment branch cover is placed on top of the BKAA floor duct branch and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the attachment branch. The floor duct attachment branch cover is made of sendzimir hot-dip galvanised steel and is not embossed. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

VDE tested according to: DIN EN 50085-2-2
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B

width

t

material thickness

Pmax

maximum load

G

Weight per storage unit

  • BKAADR 10S
    Floor duct attachment branch cover
    width
    100 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.200 kg
    More information
  • BKAADR 15S
    Floor duct attachment branch cover
    width
    150 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.240 kg
    More information
  • BKAADR 20S
    Floor duct attachment branch cover
    width
    200 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.290 kg
    More information
  • BKAADR 30S
    Floor duct attachment branch cover
    width
    300 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.370 kg
    More information
  • BKAADR 40S
    Floor duct attachment branch cover
    width
    400 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.460 kg
    More information
  • BKAADR 50S
    Floor duct attachment branch cover
    width
    500 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.550 kg
    More information
  • BKAADR 60S
    Floor duct attachment branch cover
    width
    600 mm
    material thickness
    2.00 mm
    maximum load
    5.00 kN
    Weight per storage unit
    0.630 kg
    More information

Details

  • Loadable up to 5 kN
  • Easy assembly

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link
