Snap-in ladder set for single outlet cartridge, 2x, angular
UGEAV1-2 components are square snap-in ladder sets. The snap-in ladders are mounted as mounting frames in single outlets and are used to accommodate up to two UGET1-2, UG-R or UGR 1-4 boards. The UGEAV1-2 are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346. The snap-in ladder sets can be purchased with a locking range of 25 mm.
H
height
B
width
RB
lock-in range
G
Weight per storage unit
