UDO250 2R

The UDO250 2R screed junction box is certified to DIN EN 50085-2-2 and developed for use in the screed-covered duct system UKO. Made from sendzimir hot-dip galvanized steel sheet to DIN EN 10346, it provides excellent stability and corrosion protection.

Suitable for 190 mm and 250 mm duct widths, its foldable side walls allow flexible duct connection. The two-piece box features a removable snap-on cover. The round opening (Ø 260 mm) holds the shuttering pipe USR, which is later replaced by a round dual device unit. An integrated protective earth terminal supports equipotential bonding.
