Inside bend
The range of screed-flush brush ducts also includes inside bends UBEBMBI. These products are used as connectors between two duct sections. Their angular shape allows cables to even be laid even at an internal angle of 90 degrees. These components are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346 and are 295 mm across.
H
height
B
width
L
length
N
levelling range
W
Angle
G
Weight per storage unit
