SK

Clamping claw

The SK clamping claw is used to mount the AN beam bracket on angle profiles. The clamping claw is made of hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

G

Weight per storage unit

  • SK 4 M8
    Clamping claw SK 4 M8
    height
    4 mm
    Weight per storage unit
    0.035 kg
    More information
  • SK 6 M8
    Clamping claw SK 6 M8
    height
    6 mm
    Weight per storage unit
    0.037 kg
    More information
  • SK 8 M8
    Clamping claw SK 8 M8
    height
    8 mm
    Weight per storage unit
    0.040 kg
    More information
  • SK 10 M8
    Clamping claw SK 10 M8
    height
    10 mm
    Weight per storage unit
    0.041 kg
    More information
  • SK 12 M8
    Clamping claw SK 12 M8
    height
    12 mm
    Weight per storage unit
    0.044 kg
    More information

Details
