RTR 60

Cable tray divider, height = 50 mm for escape route installation

Fire protection

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

RTR 60S
Cable tray barrier strip RTR 60S
height
50 mm
length
3000 mm
Weight per storage unit
1.528 kg
Included accessories
More information

Details

These articles have been tested for use in escape route installations.
The guidelines applicable to the specific application can be found in the relevant certificates and test reports.

Tender texts

Ausschreiben.de

Tender texts for this product

Heinze.de

Tender texts for this product

Downloads

de
P-MPA-E-14-010 - KDU57/KDU 60 - Functional maintenance certificate
General building authority test certificate
DIN 4102-12
Cable manufacturer: Kabelwerke Eupen AG
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: 20 kg/m
Fastening distance: ≤ 1.5 m
Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
Period of validity: 23/07/2029
PDF (4.94 MB)
DownloadDownload

de
P-MPA-E-16-013 - KDU57/KDU 60 - Functional maintenance certificate
General building authority test certificate
DIN 4102-12
Cable manufacturer: Studer Cables AG
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: 20 kg/m
Fastening distance: ≤ 1.5 m
Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
Period of validity: 30.08.2027
PDF (7.84 MB)
DownloadDownload

de
MPABS-2402543 - Fire protection statement
DIN 4102-12
Standardised supporting structure: Cable trays
Fire resistance duration: F30; F60; F90
Functional maintenance classes: E30; E60; F90
Cable load: ≤ 10 kg/m
Fastening distance: ≤ 1.2 m
Period of validity: 15.01.2030
PDF (11.03 MB)
DownloadDownload
