RAA-BS 60

Cable tray extension branch, height = 60 mm for escape route installation

Fire protection
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

G

Weight per storage unit

Included accessories
  • RAA-BS 60-10S
    Cable tray attachment branch-piece, fire
    height
    60 mm
    width
    100 mm
    Weight per storage unit
    0.752 kg
    Included accessories
    More information
  • RAA-BS 60-20S
    Cable tray attachment branch-piece, fire
    height
    60 mm
    width
    200 mm
    Weight per storage unit
    0.880 kg
    Included accessories
    More information
  • RAA-BS 60-30S
    Cable tray attachment branch-piece, fire
    height
    60 mm
    width
    300 mm
    Weight per storage unit
    1.012 kg
    Included accessories
    More information
  • RAA-BS 60-40S
    Cable tray add-on branch fire protection
    height
    60 mm
    width
    400 mm
    Weight per storage unit
    1.148 kg
    Included accessories
    More information
  • RAA-BS 60-50S
    Cable tray add-on branch fire protection
    height
    60 mm
    width
    500 mm
    Weight per storage unit
    1.274 kg
    Included accessories
    More information
  • RAA-BS 60-60S
    Cable tray add-on branch fire protection
    height
    60 mm
    width
    600 mm
    Weight per storage unit
    1.410 kg
    Included accessories
    More information

Details

    Tender texts

    Ausschreiben.de

    Tender texts for this product

    Open Link
    Heinze.de

    Tender texts for this product

    Open Link

    Downloads

      • de

      P-MPA-E-14-010 - KDU57/KDU 60 - Functional maintenance certificate

      General building authority test certificate
      DIN 4102-12
      Cable manufacturer: Kabelwerke Eupen AG
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: 20 kg/m
      Fastening distance: ≤ 1.5 m
      Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
      Period of validity: 23/07/2029

      PDF (4.94 MB)

      DownloadDownload

      • de

      P-MPA-E-16-013 - KDU57/KDU 60 - Functional maintenance certificate

      General building authority test certificate
      DIN 4102-12
      Cable manufacturer: Studer Cables AG
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: 20 kg/m
      Fastening distance: ≤ 1.5 m
      Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
      Period of validity: 30.08.2027

      PDF (7.84 MB)

      DownloadDownload

      • de

      MPABS-2402543 - Fire protection statement

      DIN 4102-12
      Standardised supporting structure: Cable trays
      Fire resistance duration: F30; F60; F90
      Functional maintenance classes: E30; E60; F90
      Cable load: ≤ 10 kg/m
      Fastening distance: ≤ 1.2 m
      Period of validity: 15.01.2030

      PDF (11.03 MB)

      DownloadDownload
