LGIB-BS 60

Cable ladder internal bend, height = 60 mm, maintenance of function

Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

HH

Height

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit

Geeignet für Funktionserhalt

  • LGIB-BS 60-20F
    Cable ladder inside bend, fire
    Height
    60 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.770 kg
    Geeignet für Funktionserhalt
    Ja
    More information
  • LGIB-BS 60-30F
    Cable ladder inside bend, fire
    Height
    60 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.820 kg
    Geeignet für Funktionserhalt
    Ja
    More information
  • LGIB-BS 60-40F
    Cable ladder inside bend, fire
    Height
    60 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    6.040 kg
    Geeignet für Funktionserhalt
    Ja
    More information

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Included accessories
