Art.-Nr. KHA 41-01F

Profile rail perforated 41/41x2,5

41x41 mm profile rail, perforated, maintenance of function

Fire protection

Variants

KHA 41-01F
Profile rail perforated 41/41x2,5
height
41 mm
width
41 mm
length
100 mm
material thickness
2.50 mm
Weight per storage unit
0.260 kg
More information
KHA 41-02F
Profile rail perforated 41/41x2,5
height
41 mm
width
41 mm
length
200 mm
material thickness
2.50 mm
Weight per storage unit
0.500 kg
More information
KHA 41-03F
Profile rail perforated 41/41x2,5
height
41 mm
width
41 mm
length
300 mm
material thickness
2.50 mm
Weight per storage unit
0.700 kg
More information
KHA 41-04F
Profile rail perforated 41/41x2,5
height
41 mm
width
41 mm
length
400 mm
material thickness
2.50 mm
Weight per storage unit
1.000 kg
More information
KHA 41-05F
Profile rail perforated 41/41x2,5
height
41 mm
width
41 mm
length
500 mm
material thickness
2.50 mm
Weight per storage unit
1.300 kg
More information

These articles have been tested for functional integrity in the event of fire.
The guidelines applicable to the specific application can be found in the relevant certificates and test reports.
