Art.-Nr. KDU 40-11F

Bracket Support KDU 40-11F

Bracket support, 40x30 mm, maintenance of function

Art.-Nr.
KDU 40-11F
profile height
30 mm
profile width
40 mm
length
1100 mm
material thickness
4.00 mm
Weight per storage unit
1.460 kg
Fire protection
Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

HP

profile height

BP

profile width

L

length

t

material thickness

Suitable for escape route installations

G

Weight per storage unit

  • KDU 40-02F
    Bracket Support KDU 40-02F
    profile height
    30 mm
    profile width
    40 mm
    length
    200 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    0.380 kg
    More information
  • KDU 40-03F
    Bracket Support KDU 40-03F
    profile height
    30 mm
    profile width
    40 mm
    length
    300 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    0.500 kg
    More information
  • KDU 40-04F
    Bracket Support KDU 40-04F
    profile height
    30 mm
    profile width
    40 mm
    length
    400 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    0.620 kg
    More information
  • KDU 40-05F
    Bracket Support KDU 40-05F
    profile height
    30 mm
    profile width
    40 mm
    length
    500 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    0.730 kg
    More information
  • KDU 40-06F
    Bracket Support KDU 40-06F
    profile height
    30 mm
    profile width
    40 mm
    length
    600 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    0.860 kg
    More information
  • KDU 40-07F
    Bracket Support KDU 40-07F
    profile height
    30 mm
    profile width
    40 mm
    length
    700 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    0.980 kg
    More information
  • KDU 40-08F
    Bracket Support KDU 40-08F
    profile height
    30 mm
    profile width
    40 mm
    length
    800 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.100 kg
    More information
  • KDU 40-09F
    Bracket Support KDU 40-09F
    profile height
    30 mm
    profile width
    40 mm
    length
    900 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.220 kg
    More information
  • KDU 40-10F
    Bracket Support KDU 40-10F
    profile height
    30 mm
    profile width
    40 mm
    length
    1000 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.340 kg
    More information
  • KDU 40-11F
    Bracket Support KDU 40-11F
    profile height
    30 mm
    profile width
    40 mm
    length
    1100 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.460 kg
    More information
  • KDU 40-12F
    Bracket Support KDU 40-12F
    profile height
    30 mm
    profile width
    40 mm
    length
    1200 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.580 kg
    More information
  • KDU 40-13F
    Bracket Support KDU 40-13F
    profile height
    30 mm
    profile width
    40 mm
    length
    1300 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.700 kg
    More information
  • KDU 40-14F
    Bracket Support KDU 40-14F
    profile height
    30 mm
    profile width
    40 mm
    length
    1400 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.820 kg
    More information
  • KDU 40-15F
    Bracket Support KDU 40-15F
    profile height
    30 mm
    profile width
    40 mm
    length
    1500 mm
    material thickness
    4.00 mm
    Suitable for escape route installations
    Ja
    Weight per storage unit
    1.940 kg
    More information

Details

  • Fire protection

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Downloads

    • de

    • en

    Price list 2025 Building extension

    Valid from February 1st, 2025, updated version from 31/03/2025.

    PDF

    Choose languageChoose language

    Price list 2025 Building extension

    Choose language to download

    • de

    MPABS-2402543 - Fire protection statement

    DIN 4102-12
    Standardised supporting structure: Cable trays
    Fire resistance duration: F30; F60; F90
    Functional maintenance classes: E30; E60; F90
    Cable load: ≤ 10 kg/m
    Fastening distance: ≤ 1.2 m
    Period of validity: 15.01.2030

    PDF (11.03 MB)

    DownloadDownload

    • de

    2104/681/23 - Fire protection assessment

    False ceiling installation, escape route installation, MLAR, LAR
    Fire resistance duration: F30
    Fire resistance: 30 minutes
    Fastening distance: ≤ 1.5 m
    Period of validity: 18.12.2028

    PDF (5.17 MB)

    DownloadDownload

    • de

    GA-2017/068 - Expert statement

    DIN 4102-12
    Fire protection fastening on load-bearing timber components
    Fire resistance duration: F30; F60
    Functional maintenance classes: E30; E60
    Cable load: ≤ 10 kg/m, ≤ 20 kg/m, ≤ 30 kg/m
    Mounting distance: ≤ 1.5 m
    Period of validity: 22/08/2027

    PDF (1.49 MB)

    DownloadDownload
