Clamp connection for tension-resistant and pressure-resistant connection of concrete components
JSV28 stainless steel (A4) clamp connections create play-free, tension-resistant and compression-resistant connections between two components. The connection is made between a vertical and a horizontal anchor channel with a minimum length of 150 mm. This arrangement ensures an exact, continuously variable, three-dimensional alignment of the fastening. The JSV28 clamp connection consists of a clamp sleeve, bolts and nuts with left-hand and right-hand threads, a nut for countering the clamp sleeve and washers.
H
height
B
width
L
length
G
Weight per storage unit
de
en
Valid from February 1, 2025, updated version from 27/09/2025.
de
en
Technical information
de
Valid from February 1st, 2026
PDF (17.44 MB)
DownloadDownloadAnzahl:
We support you at every step of your construction project. With high-quality products including dimensioning software for optimum planning. If the standard product is not suitable for your project, our manufacturers will configure a product that is precisely tailored to your needs.
