JMA Series 18

Brick tie anchor for fastening masonry to channels

The JMA brick tie anchor is made of stainless steel for use in the façade area. Hot-dip galvanised products (fv) can be used indoors. The brick tie anchor JMA Series 18 is suitable for profile K 38/17.

Get in touchDownload datasheet

Variants

Article

H

height

B

width

L

length

L1

length 1

L2

length 2

G

Weight per storage unit

  • MA12018 A4
    JORDAHL brick tie anchor JMA
    height
    2 mm
    width
    30 mm
    length
    145 mm
    length 1
    20 mm
    length 2
    120 mm
    Weight per storage unit
    0.083 kg
    More information
  • MA12018 FV
    JORDAHL brick tie anchor JMA
    height
    2 mm
    width
    30 mm
    length
    145 mm
    length 1
    20 mm
    length 2
    120 mm
    Weight per storage unit
    0.088 kg
    More information
  • MA18018 A4
    JORDAHL brick tie anchor JMA
    height
    2 mm
    width
    30 mm
    length
    205 mm
    length 1
    20 mm
    length 2
    180 mm
    Weight per storage unit
    0.113 kg
    More information
  • MA18018 FV
    JORDAHL brick tie anchor JMA
    height
    2 mm
    width
    30 mm
    length
    205 mm
    length 1
    20 mm
    length 2
    180 mm
    Weight per storage unit
    0.113 kg
    More information
  • MA30018 A4
    JORDAHL brick tie anchor JMA
    height
    3 mm
    width
    30 mm
    length
    325 mm
    length 1
    20 mm
    length 2
    300 mm
    Weight per storage unit
    0.168 kg
    More information
  • MA30018 FV
    JORDAHL brick tie anchor JMA
    height
    3 mm
    width
    30 mm
    length
    325 mm
    length 1
    20 mm
    length 2
    300 mm
    Weight per storage unit
    0.182 kg
    More information
  • MA8518 A4
    JORDAHL brick tie anchor JMA
    height
    2 mm
    width
    30 mm
    length
    105 mm
    length 1
    20 mm
    length 2
    85 mm
    Weight per storage unit
    0.065 kg
    More information
  • MA8518 FV
    JORDAHL brick tie anchor JMA
    height
    2 mm
    width
    30 mm
    length
    105 mm
    length 1
    20 mm
    length 2
    85 mm
    Weight per storage unit
    0.070 kg
    More information
