HW

HF trough

The high-frequency trough HW is used in combination with cable clamps for routing fibre-optic/high-frequency cables. It is suitable for cables with a maximum diameter of 1 5/8 inch and for clamps with widths from 20 to 56 mm. It is made of polystyrene.

Get in touchDownload datasheet

Variants

polystyrene

Article

B

width

L

length

D

Diameter (mm)

G

Weight per storage unit

  • HW 20-1/2
    Counter bed for HF-Cable HW 20-1/2
    width
    20 mm
    length
    55 mm
    Diameter (mm)
    17 mm
    Weight per storage unit
    0.004 kg
    More information
  • HW 32-7/8
    Counter bed for HF-Cable HW 32-7/8
    width
    32 mm
    length
    60 mm
    Diameter (mm)
    29 mm
    Weight per storage unit
    0.010 kg
    More information
  • HW 44-1 1/4
    Counter bed for HF-Cable HW 44-1 1/4
    width
    44 mm
    length
    60 mm
    Diameter (mm)
    39 mm
    Weight per storage unit
    0.017 kg
    More information
  • HW 56-1 5/8
    Counter bed for HF-Cable HW 56-1 5/8
    width
    56 mm
    length
    60 mm
    Diameter (mm)
    51 mm
    Weight per storage unit
    0.025 kg
    More information
