FS

Serrated washer

The serrated lock washers FS lock screw connections in place with a positive fit. They have an inner diameter of 6.4 to 12.5 mm. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

Get in touchDownload datasheet

Variants

steel, galvanic zinc plated

Article

D

Diameter (mm)

Ø

inner diameter

G

Weight per storage unit

  • FS 10
    Serrated lock washer FS 10
    Diameter (mm)
    18 mm
    inner diameter
    10.5 mm
    Weight per storage unit
    0.001 kg
    More information
  • FS 12
    Serrated lock washer FS 12
    Diameter (mm)
    20.5 mm
    inner diameter
    12.5 mm
    Weight per storage unit
    0.002 kg
    More information
  • FS 6
    Serrated lock washer FS 6
    Diameter (mm)
    11 mm
    inner diameter
    6.4 mm
    Weight per storage unit
    0.000 kg
    More information
  • FS 8
    Serrated lock washer FS 8
    Diameter (mm)
    14 mm
    inner diameter
    8.2 mm
    Weight per storage unit
    0.001 kg
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

D

Diameter (mm)

Ø

inner diameter

G

Weight per storage unit

  • FS 10E
    Serrated lock washer FS 10E
    Diameter (mm)
    18 mm
    inner diameter
    10.5 mm
    Weight per storage unit
    0.001 kg
    More information
  • FS 12E
    Serrated lock washer FS 12E
    Diameter (mm)
    20.5 mm
    inner diameter
    12.5 mm
    Weight per storage unit
    0.002 kg
    More information
  • FS 6E
    Serrated lock washer FS 6E
    Diameter (mm)
    11 mm
    inner diameter
    6.4 mm
    Weight per storage unit
    0.000 kg
    More information
  • FS 8E
    Serrated lock washer FS 8E
    Diameter (mm)
    14 mm
    inner diameter
    8.2 mm
    Weight per storage unit
    0.001 kg
    More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

Article

D

Diameter (mm)

Ø

inner diameter

G

Weight per storage unit

  • FS 10E4
    Serrated lock washer FS 10E4
    Diameter (mm)
    18 mm
    inner diameter
    10.5 mm
    Weight per storage unit
    0.001 kg
    More information
