DSAXPTH 2

Wire suspension with trapezoidal sheet metal hook and express closure

The wire suspension DSAXPTH 2 with trapezoidal sheet metal hook and express closure is used for suspending cable trays and mesh cable trays from ceilings. It is made of galvanised steel and is available in lengths from 1000 to 10,000 mm. The maximum load is 0.44 kN (Gripple load class 2).

Get in touchDownload datasheet

Variants

steel, galvanic zinc plated

Article

L

length

Pmax

maximum load

G

Weight per storage unit

  • DSAXPTH 21GV
    Wire rope suspension
    length
    1000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.047 kg
    More information
  • DSAXPTH 22GV
    Wire rope suspension
    length
    2000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.065 kg
    More information
  • DSAXPTH 23GV
    Wire rope suspension
    length
    3000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.083 kg
    More information
  • DSAXPTH 24GV
    Wire rope suspension
    length
    4000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.100 kg
    More information
  • DSAXPTH 25GV
    Wire rope suspension
    length
    5000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.123 kg
    More information
  • DSAXPTH 210GV
    Wire rope suspension
    length
    10000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.210 kg
    More information

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

BIM- und CAD-Data

    BIM Data Cablele Support System Fastening Accessories (Revit)

    BIM Data

    ZIP, 39.32 MB

    DownloadDownload
