Art.-Nr. DSAXPET8 210GV

Wire rope suspension

Wire suspension with M8 threaded transition and express closure

The wire suspension DSAXPET8 2 with M8 threaded transition and express lock is used for suspending cable trays and mesh cable trays from ceilings. It is made of galvanised steel and is available in lengths from 1000 to 10,000 mm. The maximum load is 0.44 kN (Gripple load class 2).

Art.-Nr.
DSAXPET8 210GV
length
10000 mm
maximum load
0.44 kN
Weight per storage unit
0.215 kg
Get in touchDownload datasheet

Variants

steel, galvanic zinc plated

Article

L

length

Pmax

maximum load

G

Weight per storage unit

  • DSAXPET8 21GV
    Wire rope suspension
    length
    1000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.060 kg
    More information
  • DSAXPET8 22GV
    Wire rope suspension
    length
    2000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.077 kg
    More information
  • DSAXPET8 23GV
    Wire rope suspension
    length
    3000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.096 kg
    More information
  • DSAXPET8 24GV
    Wire rope suspension
    length
    4000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.113 kg
    More information
  • DSAXPET8 25GV
    Wire rope suspension
    length
    5000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.132 kg
    More information
  • DSAXPET8 210GV
    Wire rope suspension
    length
    10000 mm
    maximum load
    0.44 kN
    Weight per storage unit
    0.215 kg
    More information
