DSAUGRTH 2

Wire suspension with trapezoidal sheet metal hook and UniGrip central exit

The wire suspension DSAUGRTH 2 with trapezoidal sheet metal hook and UniGrip central exit is used for suspending cable trays and mesh cable trays from ceilings. It is made of galvanised steel and is available in lengths from 1000 to 10,000 mm. The maximum load is 0.54 kN (Gripple load class 2).

Get in touchDownload datasheet

Variants

steel, galvanic zinc plated

Article

L

length

Pmax

maximum load

G

Weight per storage unit

  • DSAUGRTH 21GV
    Wire rope suspension
    length
    1000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.350 kg
    More information
  • DSAUGRTH 22GV
    Wire rope suspension
    length
    2000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.370 kg
    More information
  • DSAUGRTH 23GV
    Wire rope suspension
    length
    3000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.390 kg
    More information
  • DSAUGRTH 24GV
    Wire rope suspension
    length
    4000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.410 kg
    More information
  • DSAUGRTH 25GV
    Wire rope suspension
    length
    5000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.430 kg
    More information
  • DSAUGRTH 210GV
    Wire rope suspension
    length
    10000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.680 kg
    More information
