DSAUGFR 2

Wire suspension with loop and UniGrip standard closure

The wire suspension DSAUGFR 2 with loop and UniGrip standard closure is used for suspending cable trays and mesh cable trays from ceilings. It is made of galvanised steel and is available in lengths from 1000 to 10,000 mm. The maximum load is 0.54 kN (Gripple load class 2).

Get in touchDownload datasheet

Variants

steel, galvanic zinc plated

Article

L

length

Pmax

maximum load

G

Weight per storage unit

  • DSAUGFR 21GV
    Wire rope suspension
    length
    1000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.280 kg
    More information
  • DSAUGFR 22GV
    Wire rope suspension
    length
    2000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.300 kg
    More information
  • DSAUGFR 23GV
    Wire rope suspension
    length
    3000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.320 kg
    More information
  • DSAUGFR 24GV
    Wire rope suspension
    length
    4000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.340 kg
    More information
  • DSAUGFR 25GV
    Wire rope suspension
    length
    5000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.360 kg
    More information
  • DSAUGFR 210GV
    Wire rope suspension
    length
    10000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.600 kg
    More information

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

BIM- und CAD-Data

    BIM Data Cablele Support System Fastening Accessories (Revit)

    BIM Data

    ZIP, 39.32 MB

    DownloadDownload
