DSAUGEF8 2

Wire suspension with M8 threaded end and UniGrip standard closure

The wire suspension DSAUGEF8 2 with M8 threaded end and UniGrip standard closure is used for suspending cable trays and mesh cable trays from ceilings. It is made of galvanised steel and is available in lengths from 1000 to 10,000 mm. The maximum load is 0.54 kN (Gripple load class 2).

Get in touchDownload datasheet

Variants

steel, galvanic zinc plated

Article

L

length

Pmax

maximum load

G

Weight per storage unit

  • DSAUGEF8 21GV
    Wire rope suspension
    length
    1000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.320 kg
    More information
  • DSAUGEF8 22GV
    Wire rope suspension
    length
    2000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.340 kg
    More information
  • DSAUGEF8 23GV
    Wire rope suspension
    length
    3000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.360 kg
    More information
  • DSAUGEF8 24GV
    Wire rope suspension
    length
    4000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.380 kg
    More information
  • DSAUGEF8 25GV
    Wire rope suspension
    length
    5000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.400 kg
    More information
  • DSAUGEF8 210GV
    Wire rope suspension
    length
    10000 mm
    maximum load
    0.54 kN
    Weight per storage unit
    0.650 kg
    More information
