BKHCSV

Floor duct side trim

BKHCSV floor duct side trim is used when the floor duct is elevated by BKHC floor duct brackets and is fastened using a BS 5.5x19 drilling screw. The side trims protect raised floor ducts from footfall and dirt and close off the floor duct system underneath. They are 90 mm high, 1000, 1500 or 3000 mm long and are made of sendzimir hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

L

length

t

material thickness

G

Weight per storage unit

  • BKHCSV 1.5S
    Floor duct side trim
    height
    90 mm
    length
    1500 mm
    material thickness
    1.00 mm
    Weight per storage unit
    1.060 kg
    More information
  • BKHCSV 1S
    Floor duct side trim
    height
    90 mm
    length
    1000 mm
    material thickness
    1.00 mm
    Weight per storage unit
    0.710 kg
    More information
  • BKHCSV S
    Floor duct side trim
    height
    90 mm
    length
    3000 mm
    material thickness
    1.00 mm
    Weight per storage unit
    2.120 kg
    More information
