Pipe clamp for mounting channels
The pipe clamp AVRS is used to fasten pipes in C mounting channels (A 41, KHA 41, KHAL 41) with 22 mm slot width. It has a fastening hole with Ø 14 mm and is made of hot-dip galvanised steel. Fastening accessories must be ordered separately, depending on the application.
H
height
B
width
t
material thickness
D
Diameter (mm)
G
Weight per storage unit
de
en
Compact overview for KHA 21, KHA 41, KHA 82, KLUGW, SKL A, BGUD, BLD, BGA 41, BGA 41/2, KA 30, KA 41, KDAG 41, AVSK, AVSKH, AVSKGB, AVSKA, AVRS, AVLW, SAI 41, SA 2, BGF 41, BGF 82, KLUGS, KHAD 22, AVLK, AKL 41, AVL, AVLW 45, GK-A, AVLWBF, AVBLA, AVA, AVB, AMK 22, AVE, AVBL, AVAW, AVLWB, AVT, BL 5
