UKR screed-covered underfloor duct systems with two or three sections are used when laying large quantities of cables and lines in office buildings, in the industrial sector and for technical building services. The duct systems consist of a base, a dummy cover and one or two separating strips. The bottom parts are fixed to the raw slab using the separating strips before the screed is applied and are securely closed with the suitable covers after the cables have been inserted. The products compensate for structural tolerances and can be used flexibly and regardless of the room’s purpose and screed type.
UKR Underfloor Duct System
UKR 2
Cable duct base, two sections
UKR 3
Cable duct base, three sections
UKD
Cable duct dummy cover
UKDA 308R
Cable duct assembly cover, 3x, round
UKDA 260V
Cable duct assembly cover, 3x, angular
UKDA 260R
Cable duct assembly cover, 2x, round
UKDA 185V
Cable duct assembly cover, 2x, angular
UKEB
End plate
UKAZ
Attachment accessories
UKTR
Separating strip
Vorteile
- Suitable for large volumes of cable due to variable side rail heights and widths
- Simple assembly of the system directly on site
- Cables and lines can be laid before the screed is applied.
- Suitable for all types of screed
- Compensates for structural tolerances
- Customisable on request
